源码 kakfa 3.0 创建topic流程

文章目录

1、通过create命令到组装创建topic需要的数据流程(scala部分)
2、创建一个客户端，此客户端通过队列多线程异步发送创建topic的请求
- (1)runnable.call(队列和多线程执行)
- (2)getCreateTopicsCall(创建发送创建topic的requestBuilder)
3、服务端创建topic的请求(handleCreateTopicsRequest）
- （1）这里先看一下kafka集群启动时的操作
- （2）在初始化KafkaApis时如何选择是zk的还是raft的
- (3)、这里卡住了，

1、通过create命令到组装创建topic需要的数据流程(scala部分) 首先创建kafka topic的命令是下面这个

bin/kafka-topics.sh --bootstrap-server broker_host:port --create --topic my_topic_name \--partitions 20 --replication-factor 3 --config x=y

--bootstrap-server 某一台kafka服务器地址和端口
--create 代表这个命令是创建
--topic 后面是想创建的topic
partitions 主动设置分区数
--replication-factor 主动设置一个分区数中有几个副本
--config x=y 在命令行上添加的配置会覆盖服务器的默认设置，例如数据应该保留的时间长度。此处记录了完整的每个主题配置集。选填
之后再看kafka-topics.sh 里面的命令
exec $(dirname $0)/kafka-run-class.sh kafka.admin.TopicCommand "$@" 知道了其实是执行了源码core/src/main/scala/kafka/admin/TopicCommand.scala文件中的方法
这里需要注意的是从kafka 2.8以后，删除了ZooKeeper ，通过KRaft进行自己的集群管理，所以下面源码中没有ZookeeperTopicService 这个创建topic的方法了

object TopicCommand extends Logging {def main(args: Array[String]): Unit = {val opts = new TopicCommandOptions(args)opts.checkArgs()	//初始化得到实例化的topicServiceval topicService = TopicService(opts.commandConfig, opts.bootstrapServer)var exitCode = 0try {if (opts.hasCreateOption)//这个是通过判断命令中的是否是--create 关键字来判断是否执行createTopictopicService.createTopic(opts)else if (opts.hasAlterOption)topicService.alterTopic(opts)else if (opts.hasListOption)topicService.listTopics(opts)else if (opts.hasDescribeOption)topicService.describeTopic(opts)else if (opts.hasDeleteOption)topicService.deleteTopic(opts)} catch {case e: ExecutionException =>if (e.getCause != null)printException(e.getCause)elseprintException(e)exitCode = 1case e: Throwable =>printException(e)exitCode = 1} finally {topicService.close()Exit.exit(exitCode)}}

TopicService(opts.commandConfig, opts.bootstrapServer) 执行的是下面的方法中的apply

 object TopicService {def createAdminClient(commandConfig: Properties, bootstrapServer: Option[String]): Admin = {bootstrapServer match {case Some(serverList) => commandConfig.put(CommonClientConfigs.BOOTSTRAP_SERVERS_CONFIG, serverList)case None =>}Admin.create(commandConfig)}def apply(commandConfig: Properties, bootstrapServer: Option[String]): TopicService =new TopicService(createAdminClient(commandConfig, bootstrapServer))}

之后又调用的createAdminClient创建的一个客户端，来创建topic
下面就是验证参数，是否指定参数设置等等，之后调用新创建的clien创建topic

case class TopicService private (adminClient: Admin) extends AutoCloseable {def createTopic(opts: TopicCommandOptions): Unit = {//创建一个topic ， 把输入参数 ， 比如分区数 ， 副本数等等参数设置上val topic = new CommandTopicPartition(opts)if (Topic.hasCollisionChars(topic.name)) //检查topic名称中的特殊字符println("WARNING: Due to limitations in metric names, topics with a period ('.') or underscore ('_') could " +"collide. To avoid issues it is best to use either, but not both.")createTopic(topic)}def createTopic(topic: CommandTopicPartition): Unit = {// //如果配置了副本副本数--replication-factor 一定要大于0if (topic.replicationFactor.exists(rf => rf > Short.MaxValue || rf < 1))throw new IllegalArgumentException(s"The replication factor must be between 1 and ${Short.MaxValue} inclusive")//如果配置了--partitions 分区数 必须大于0if (topic.partitions.exists(partitions => partitions < 1))throw new IllegalArgumentException(s"The partitions must be greater than 0")try {val newTopic = if (topic.hasReplicaAssignment)// 如果指定了--replica-assignment参数；则按照指定的来分配副本new NewTopic(topic.name, asJavaReplicaReassignment(topic.replicaAssignment.get))else {new NewTopic(topic.name,topic.partitions.asJava,topic.replicationFactor.map(_.toShort).map(Short.box).asJava)}//将配置--config 解析成一个配置mapval configsMap = topic.configsToAdd.stringPropertyNames().asScala.map(name => name -> topic.configsToAdd.getProperty(name)).toMap.asJavanewTopic.configs(configsMap)//调用adminClient创建Topicval createResult = adminClient.createTopics(Collections.singleton(newTopic),new CreateTopicsOptions().retryOnQuotaViolation(false))createResult.all().get()println(s"Created topic ${topic.name}.")} catch {case e : ExecutionException =>if (e.getCause == null)throw eif (!(e.getCause.isInstanceOf[TopicExistsException] && topic.ifTopicDoesntExist()))throw e.getCause}}

2、创建一个客户端，此客户端通过队列多线程异步发送创建topic的请求在KafkaAdminClient.java 中的createTopics方法

@Overridepublic CreateTopicsResult createTopics(final Collection newTopics,final CreateTopicsOptions options) {final Map topicFutures = new HashMap<>(newTopics.size());final CreatableTopicCollection topics = new CreatableTopicCollection();//遍历要创建的topic集合for (NewTopic newTopic : newTopics) {if (topicNameIsUnrepresentable(newTopic.name())) {//topic名称不存在KafkaFutureImpl future = new KafkaFutureImpl<>();future.completeExceptionally(new InvalidTopicException("The given topic name '" +newTopic.name() + "' cannot be represented in a request."));topicFutures.put(newTopic.name(), future);} else if (!topicFutures.containsKey(newTopic.name())) {//防止发一次创建多个topic时有重复的topicFutures.put(newTopic.name(), new KafkaFutureImpl<>());topics.add(newTopic.convertToCreatableTopic());}}//如果topics不为null 。则去创建if (!topics.isEmpty()) {final long now = time.milliseconds();final long deadline = calcDeadlineMs(now, options.timeoutMs());//初始化创建topic的调用 ， final Call call = getCreateTopicsCall(options, topicFutures, topics,Collections.emptyMap(), now, deadline);//这里面才是调用 ， 上面call只是初始化runnable.call(call, now);}return new CreateTopicsResult(new HashMap<>(topicFutures));}

(1)runnable.call(队列和多线程执行) 为什么先讲解这个？而不是先getCreateTopicsCall？因为我觉得先看这个比较好理解，因为它不是单调执行的一步到位，比如先看getCreateTopicsCall会有点迷糊

 /*** Initiate a new call.*发起新呼叫* This will fail if the AdminClient is scheduled to shut down.*如果 AdminClient 计划关闭 ， 这将失败* @param callThe new call object.* @param nowThe current time in milliseconds.*/void call(Call call, long now) {if (hardShutdownTimeMs.get() != INVALID_SHUTDOWN_TIME) {log.debug("The AdminClient is not accepting new calls. Timing out {}.", call);call.handleTimeoutFailure(time.milliseconds(),new TimeoutException("The AdminClient thread is not accepting new calls."));} else {enqueue(call, now);}}/*** Queue a call for sending.*排队发送呼叫* If the AdminClient thread has exited, this will fail. Otherwise, it will succeed (even* if the AdminClient is shutting down). This function should called when retrying an* existing call.*如果 AdminClient 线程已退出 ， 这将失败 。否则 ， 它将成功（即使 如果 AdminClient 正在关闭） 。* 重试现有调用时应调用此函数* @param callThe new call object.* @param nowThe current time in milliseconds.*/void enqueue(Call call, long now) {if (call.tries > maxRetries) {log.debug("Max retries {} for {} reached", maxRetries, call);call.handleTimeoutFailure(time.milliseconds(), new TimeoutException("Exceeded maxRetries after " + call.tries + " tries."));return;}if (log.isDebugEnabled()) {log.debug("Queueing {} with a timeout {} ms from now.", call,Math.min(requestTimeoutMs, call.deadlineMs - now));}boolean accepted = false;//把call放到一个newCalls队列中synchronized (this) {if (!closing) {newCalls.add(call);accepted = true;}}//唤醒线程去执行if (accepted) {client.wakeup(); // wake the thread if it is in poll()如果线程处于轮询中 ， 则唤醒线程} else {log.debug("The AdminClient thread has exited. Timing out {}.", call);call.handleTimeoutFailure(time.milliseconds(),new TimeoutException("The AdminClient thread has exited."));}}

client.wakeup()唤醒的线程执行下面的

@Overridepublic void run() {log.debug("Thread starting");try {//这里是处理请求processRequests();} finally {closing = true;//省略log.debug("Exiting AdminClientRunnable thread.");}}private void processRequests() {long now = time.milliseconds();while (true) {// Copy newCalls into pendingCalls.//将 newCalls 复制到 pendingCallsdrainNewCalls();// Check if the AdminClient thread should shut down.//检查 AdminClient 线程是否应该关闭long curHardShutdownTimeMs = hardShutdownTimeMs.get();if ((curHardShutdownTimeMs != INVALID_SHUTDOWN_TIME) && threadShouldExit(now, curHardShutdownTimeMs))break;// Handle timeouts.//处理超时TimeoutProcessor timeoutProcessor = timeoutProcessorFactory.create(now);timeoutPendingCalls(timeoutProcessor);timeoutCallsToSend(timeoutProcessor);timeoutCallsInFlight(timeoutProcessor);long pollTimeout = Math.min(1200000, timeoutProcessor.nextTimeoutMs());if (curHardShutdownTimeMs != INVALID_SHUTDOWN_TIME) {pollTimeout = Math.min(pollTimeout, curHardShutdownTimeMs - now);}// Choose nodes for our pending calls.为我们的待处理呼叫选择节点pollTimeout = Math.min(pollTimeout, maybeDrainPendingCalls(now));long metadataFetchDelayMs = metadataManager.metadataFetchDelayMs(now);if (metadataFetchDelayMs == 0) {metadataManager.transitionToUpdatePending(now);Call metadataCall = makeMetadataCall(now);// Create a new metadata fetch call and add it to the end of pendingCalls.//创建一个新的元数据获取调用并将其添加到 pendingCalls 的末尾// Assign a node for just the new call (we handled the other pending nodes above).//为新调用分配一个节点（我们处理了上面的其他待处理节点） 。if (!maybeDrainPendingCall(metadataCall, now))pendingCalls.add(metadataCall);}pollTimeout = Math.min(pollTimeout, sendEligibleCalls(now));if (metadataFetchDelayMs > 0) {pollTimeout = Math.min(pollTimeout, metadataFetchDelayMs);}// Ensure that we use a small poll timeout if there are pending calls which need to be sent//如果有待发送的呼叫需要发送 ， 请确保我们使用一个小的轮询超时if (!pendingCalls.isEmpty())pollTimeout = Math.min(pollTimeout, retryBackoffMs);// Wait for network responses.//等待网络响应log.trace("Entering KafkaClient#poll(timeout={})", pollTimeout);List responses = client.poll(Math.max(0L, pollTimeout), now);log.trace("KafkaClient#poll retrieved {} response(s)", responses.size());// unassign calls to disconnected nodes//取消对断开节点的调用unassignUnsentCalls(client::connectionFailed);// Update the current time and handle the latest responses.//更新当前时间并处理最新响应now = time.milliseconds();handleResponses(now, responses);}}

sendEligibleCalls 这个方法是实际调用的call的方法

 /*** Send the calls which are ready.*发送准备好的电话* @param nowThe current time in milliseconds.* @returnThe minimum timeout we need for poll().*/private long sendEligibleCalls(long now) {long pollTimeout = Long.MAX_VALUE;for (Iterator> iter = callsToSend.entrySet().iterator(); iter.hasNext(); ) {Map.Entry> entry = iter.next();List calls = entry.getValue();if (calls.isEmpty()) {iter.remove();continue;}//省略 。。。while (!calls.isEmpty()) {Call call = calls.remove(0);int timeoutMs = Math.min(remainingRequestTime,calcTimeoutMsRemainingAsInt(now, call.deadlineMs));AbstractRequest.Builder requestBuilder;try {//获得call中的requestBuilderrequestBuilder = call.createRequest(timeoutMs);} catch (Throwable t) {call.fail(now, new KafkaException(String.format("Internal error sending %s to %s.", call.callName, node), t));continue;}ClientRequest clientRequest = client.newClientRequest(node.idString(),requestBuilder, now, true, timeoutMs, null);log.debug("Sending {} to {}. correlationId={}, timeoutMs={}",requestBuilder, node, clientRequest.correlationId(), timeoutMs);//实际调用请求client.send(clientRequest, now);callsInFlight.put(node.idString(), call);correlationIdToCalls.put(clientRequest.correlationId(), call);break;}}return pollTimeout;}

这里需要多注意一下requestBuilder = call.createRequest(timeoutMs); 这一行，下面getCreateTopicsCall才是requestBuilder 的初始化
(2)getCreateTopicsCall(创建发送创建topic的requestBuilder) 看完上面的runnable.call,下面接着看getCreateTopicsCall如何生成Call 的。

 private Call getCreateTopicsCall(final CreateTopicsOptions options,final Map, KafkaFutureImpl> futures,final CreatableTopicCollection topics,final Map, ThrottlingQuotaExceededException> quotaExceededExceptions,final long now,final long deadline) {return new Call("createTopics", deadline, new ControllerNodeProvider()) {@Overridepublic CreateTopicsRequest.Builder createRequest(int timeoutMs) {return new CreateTopicsRequest.Builder(new CreateTopicsRequestData().setTopics(topics).setTimeoutMs(timeoutMs).setValidateOnly(options.shouldValidateOnly()));}@Overridepublic void handleResponse(AbstractResponse abstractResponse) {//省略..}private ConfigEntry configEntry(CreatableTopicConfigs config) {return new ConfigEntry(config.name(),config.value(),configSource(DescribeConfigsResponse.ConfigSource.forId(config.configSource())),config.isSensitive(),config.readOnly(),Collections.emptyList(),null,null);}@Overridevoid handleFailure(Throwable throwable) {// If there were any topics retries due to a quota exceeded exception, we propagate// the initial error back to the caller if the request timed out.maybeCompleteQuotaExceededException(options.shouldRetryOnQuotaViolation(),throwable, futures, quotaExceededExceptions, (int) (time.milliseconds() - now));// Fail all the other remaining futurescompleteAllExceptionally(futures.values(), throwable);}};}

其中new ControllerNodeProvider() 返回的是controller列表，这样的话相当于服务端是用controller接收的，

 /*** Provides the controller node.* 提供控制器节点*/private class ControllerNodeProvider implements NodeProvider {@Overridepublic Node provide() {if (metadataManager.isReady() &&(metadataManager.controller() != null)) {return metadataManager.controller();}metadataManager.requestUpdate();return null;}}

3、服务端创建topic的请求(handleCreateTopicsRequest）（1）这里先看一下kafka集群启动时的操作为什么要加这一步?
主要是因为从kafka2.8开始，除了zk我们又有新的选择，用kraft来做zk的工作，并被称为革命性的，但是旧的zk其实没有被废弃，只是提供了新的选择
可以去看我另一篇文章:kafka 2.8 如何选择启用kraft还是ZooKeeper(选择逻辑源码，不涉及到kraft的实现)
（2）在初始化KafkaApis时如何选择是zk的还是raft的在启动kafka时，会调用startup做初始化
后面只演示KafkaRaftServer

def startup(): Unit = {	//省略// Create the request processor objects.//创建请求处理器对象 ， 这里需要特别注意raftSupport 和在new KafkaApis中参数的位置 。val raftSupport = RaftSupport(forwardingManager, metadataCache)dataPlaneRequestProcessor = new KafkaApis(socketServer.dataPlaneRequestChannel, raftSupport,replicaManager, groupCoordinator, transactionCoordinator, autoTopicCreationManager,config.nodeId, config, metadataCache, metadataCache, metrics, authorizer, quotaManagers,fetchManager, brokerTopicStats, clusterId, time, tokenManager, apiVersionManager)dataPlaneRequestHandlerPool = new KafkaRequestHandlerPool(config.nodeId,socketServer.dataPlaneRequestChannel, dataPlaneRequestProcessor, time,config.numIoThreads, s"${SocketServer.DataPlaneMetricPrefix}RequestHandlerAvgIdlePercent",SocketServer.DataPlaneThreadPrefix)//省略 }

这里看一下KafkaApis 的构造代码，可以认为服务端是controller的列表，在KafkaApis.scala 文件中

/** * Logic to handle the various Kafka requests */class KafkaApis(val requestChannel: RequestChannel,val metadataSupport: MetadataSupport,val replicaManager: ReplicaManager,val groupCoordinator: GroupCoordinator,val txnCoordinator: TransactionCoordinator,val autoTopicCreationManager: AutoTopicCreationManager,val brokerId: Int,val config: KafkaConfig,val configRepository: ConfigRepository,val metadataCache: MetadataCache,val metrics: Metrics,val authorizer: Option[Authorizer],val quotas: QuotaManagers,val fetchManager: FetchManager,brokerTopicStats: BrokerTopicStats,val clusterId: String,time: Time,val tokenManager: DelegationTokenManager,val apiVersionManager: ApiVersionManager) extends ApiRequestHandler with Logging

其中第二个位置MetadataSupport ，在startup中是raftSuppert ，所以后面的源码如果出现MetadataSupport调用如果获得的字段是带zk ，不要认为就是zk相关的，其实是raft
创建的客户端发送的创建topic请求是由handleCreateTopicsRequest接收处理，

 /*** Top-level method that handles all requests and multiplexes to the right api* 处理所有请求并多路复用到正确 api 的顶级方法*/override def handle(request: RequestChannel.Request, requestLocal: RequestLocal): Unit = {try {//省略 。。。request.header.apiKey match {//省略 。。case ApiKeys.CREATE_TOPICS => maybeForwardToController(request, handleCreateTopicsRequest)//省略 。。}} catch {//省略} finally {//省略}}

maybeForwardToController 这个就不多做解释，直接看handleCreateTopicsRequest吧

def handleCreateTopicsRequest(request: RequestChannel.Request): Unit = {//虽然字段名是zkSupport 但实际上是raftSupport ， 原因看3(1)val zkSupport = metadataSupport.requireZkOrThrow(KafkaApis.shouldAlwaysForward(request))//省略val createTopicsRequest = request.body[CreateTopicsRequest]val results = new CreatableTopicResultCollection(createTopicsRequest.data.topics.size)//如果当前Broker不是属于Controller的话,就抛出异常if (!zkSupport.controller.isActive) {createTopicsRequest.data.topics.forEach { topic =>results.add(new CreatableTopicResult().setName(topic.name).setErrorCode(Errors.NOT_CONTROLLER.code))}sendResponseCallback(results)} else {//省略zkSupport.adminManager.createTopics(createTopicsRequest.data.timeoutMs,createTopicsRequest.data.validateOnly,toCreate,authorizedForDescribeConfigs,controllerMutationQuota,handleCreateTopicsResults) }

zkSupport.adminManager.createTopics这里面是实际的调用，
(3)、这里卡住了， 1、zkSupport.adminManager.createTopics为什么走的是ZkAdminManager中的createTopics方法，不应该有个RaftAdminManager的吗？
2、val zkSupport = metadataSupport.requireZkOrThrow 的实现

case class ZkSupport(adminManager: ZkAdminManager,controller: KafkaController,zkClient: KafkaZkClient,forwardingManager: Option[ForwardingManager],metadataCache: ZkMetadataCache) extends MetadataSupport {val adminZkClient = new AdminZkClient(zkClient)override def requireZkOrThrow(createException: => Exception): ZkSupport = thisoverride def requireRaftOrThrow(createException: => Exception): RaftSupport = throw createExceptionoverride def ensureConsistentWith(config: KafkaConfig): Unit = {if (!config.requiresZookeeper) {throw new IllegalStateException("Config specifies Raft but metadata support instance is for ZooKeeper")}}override def maybeForward(request: RequestChannel.Request,handler: RequestChannel.Request => Unit,responseCallback: Option[AbstractResponse] => Unit): Unit = {forwardingManager match {case Some(mgr) if !request.isForwarded && !controller.isActive => mgr.forwardRequest(request, responseCallback)case _ => handler(request)}}override def controllerId: Option[Int] =metadataCache.getControllerId}case class RaftSupport(fwdMgr: ForwardingManager, metadataCache: KRaftMetadataCache)extends MetadataSupport {override val forwardingManager: Option[ForwardingManager] = Some(fwdMgr)override def requireZkOrThrow(createException: => Exception): ZkSupport = throw createExceptionoverride def requireRaftOrThrow(createException: => Exception): RaftSupport = thisoverride def ensureConsistentWith(config: KafkaConfig): Unit = {if (config.requiresZookeeper) {throw new IllegalStateException("Config specifies ZooKeeper but metadata support instance is for Raft")}}override def maybeForward(request: RequestChannel.Request,handler: RequestChannel.Request => Unit,responseCallback: Option[AbstractResponse] => Unit): Unit = {if (!request.isForwarded) {fwdMgr.forwardRequest(request, responseCallback)} else {handler(request) // will reject}}

如果是zk模式则是ZkSupport下的requireZkOrThrow 还好理解，如果是raft则是RaftSupport的requireZkOrThrow ，那override def requireZkOrThrow(createException: => Exception): ZkSupport = throw createException 返回给handleCreateTopicsRequest的zkSupport 还用继续走下面的zkSupport.adminManager.createTopics 吗？
【源码 kakfa 3.0 创建topic流程】有知道的给个解释吧？或者以后再看看
